5-40
IM 760201-01E
5.15
Measuring the
A
verage
Active Power
Explanation
The equation for computing the average active power is specified using a user-defined
function as follows:
Average active power =
Integrated power
Elapsed integration time
For example, to determine the average active power of element 1, set the equation of a
user-defined function as follows:
WH(E1)/(TI(E1)*3600)
The unit of TI values is seconds. For instructions on how to set user-defined functions,
see section 5.13.
