YOKOGAWA WT500 User Manual

ii
IM 760201-01E
Checking the Package Contents
After receiving the product and opening the package, check the items described below.
If the wrong items have been delivered, if items are missing, or if there is a problem with
the appearance of the items, contact your nearest YOKOGAWA dealer.
WT500
Check that the model name and suffix code given on the name plate on the side panel
are the same as those on your order.
MODEL
SUFFIX
NO.
Made in Japan
MODEL
SUFFIX
NO.
Made in Japan
MODEL and SUFFIX Codes
Model/Item Suffix Code Description
760201
760202
760203
Number of installed input elements: 1
Number of installed input elements: 2
Number of installed input elements: 3
Power cord -D UL, CSA standard power cord
-F VDE standard power cord
-Q BS standard power cord
-R AS standard power cord
-H GB standard power cord (CCC-compatible)
Options /C1 GP-IB interface
/C7 Ethernet interface
/EX1 External sensor input (only selectable with the 760201)
/EX2 External sensor input (only selectable with the 760202)
/EX3 External sensor input (only selectable with the 760203)
/G5 Harmonic measurement
/DT Delta computation
/FQ Frequency measurement add-on (enables simultaneous
measurement of all input elements)
/V1 VGA output
Suffix Code Example
On a model with three input elements installed that comes with the GP
-IB interface, external
input sensor, and harmonic measurement options and a UL, CSA standard power cord, the
suffix code is 760203-D/C1/EX3/G5.
NO. (Instrument number)
When contacting the dealer from which you purchased the instrument, please give them
the instrument number.
