9-8
IM 760201-01E
9.5 Choosing Where to Store Numeric Data
CAUTION
Do not remove USB memory or turn off the power when the screen icon that
indicates USB access or USB memory access indicators are blinking. If you do, the
USB memory may be damaged, and its data may be corrupted.
Procedure
1.
Press SHIFT+STORE (STORE SET) to display the Store Set menu.
2.
Use the cursor keys to select File Settings.
3.
Press SET to display the Store File Settings dialog box.
Selecting a Storage Medium
4.
Use the cursor keys to select File List.
5.
Press SET to display the File List dialog box.
6.
Use the cursor keys to select the storage medium (displayed using brackets) that
you want to save to.
7.
Press SET to confirm the storage media selection.
Selecting a Directory
(Follow these procedures if the storage medium has directories.)
8.
Use the cursor keys to select the directory (displayed using < >) that you want to
save to.
9.
Press SET to confirm the directory selection.
The selected storage medium and directory appear in the upper left of the File List dialog
box after “Path=.”
Select <..> and press
SET
to move up to the parent directory.
10.
Press ESC to close the File List dialog box.
