YOKOGAWA WT500 User Manual

1-6
IM 760201-01E
Keys for Displaying Measured/Computed Results
SETUP
INPUT INFO
DISPLAY
NUMERIC WAVE OTHERS
FORM ITEM
CURSOR
INTEGRATOR
START/
STOP
RESET
HOLD
SINGLE
SHIFT MISC
NULL
LOCAL
KEY LOCK
NUMERIC (See sections 3.16, 5.1, and 6.2)
Use this key to display numeric data.
• Each time you press NUMERIC, the number of displayed items switches in this order:
4 Items > 8 Items > 16 Items > Matrix > All Items > Single List
*
> Dual List
*
> 4 Items >
and so on.
* Only appears on models with the harmonic measurement option.
• When you are displaying numeric data, you can press FORM, which is described later
in this section, to display a menu for changing the number of displayed items.
•
When you are displaying numeric data, you can press ITEM, which is described later
in this section, to display a menu for changing the displayed items.
WAVE (See sections 3.16, 6.7, and 7.2)
Use this key to display waveforms.
• Each time you press WAVE, the waveform display split screen setting switches in this
order: Single > Dual > Triad > Quad > Single > and so on.
•
When you are displaying waveforms, you can press FORM, which is described later
in this section, to display a menu for setting the time-axis of the displayed waveforms,
the trigger for waveform display, the number of waveform display split screens, and
the assignment of waveforms to split screens.
•
When you are displaying waveforms, you can press ITEM, which is described later
in this section, to display a menu for selecting and zooming in on the displayed
waveforms.
OTHERS (See sections 3.16, 6.7, 6.8, 7.2, and 8.2)
Use this key to switch between the Trend, Bar Graph
*
, and Vector
*
displays.
Each time you press OTHERS, the display switches in this order: Trend > Bar* > Vector*
> Trend > and so on.
* Only appears on models with the harmonic measurement option.
FORM (See sections 5.2, 6.2, 6.7, 6.8, 7.4, 7.5, 7.7, 7.8, and 8.6 to 8.9)
Use this key to display a menu for setting the format of the display that has been selected
using NUMERIC, WAVE, or OTHERS.
SHIFT+FORM (CURSOR) Key Combination (See sections 7.9 and 8.10)
Use this key when you are displaying waveforms, trends, or bar graphs* to display a
menu for using cursors to measure waveform and graph values.
* Only appears on models with the harmonic measurement option.
ITEM Key (See sections 5.2, 6.2, 6.7, 6.8, 7.3, 7.6, and 8.3 to 8.5)
Use this key to display a menu for setting the displayed items in the display that has
been selected using NUMERIC, WAVE, or OTHERS.
Keys for Data Storage/Saving
FILE IMAGE
MENU
STORE
STORE SET
FILE
Use this key to display a menu for saving and loading setup parameters, saving
measured data, deleting files, copying files, and so on.
Use this key to save the screen image data.
SHIFT+IMAGE (MENU) Key Combination
Use this key combination to display a menu for setting screen image data save options
such as the file name, data format, color mode, data compression, and comments.
STORE
Use this key to execute, stop, or reset a storage operation.
SHIFT+STORE (STORE SET) Key Combination
Use this key to display a setup menu for the storage feature.
1.2 Setup Menu Display and Operation Keys
