YOKOGAWA WT500 User Manual

App-7
IM 760201-01E
Appendix
3
2
1
4
5
6
7
8
9
10
11
12
13
14
App
Index
Appendix 2 List of Initial Settings and Numeric Data
Display Order
Factory Default Settings (Example for a Model with Three Input Elements
Installed)
The default settings vary depending on the number of installed input elements and what
options are installed.
Item Setting
Wiring
Wiring Setting 1P2W
Element Independent Off
η
Formula
η
1 P3/P
Σ
η
2 P
Σ
/P3
Udef1 P1+None+None+None
Udef2 P1+None+None+None
Ranges
U Range 1000V
I input Terminal Direct
I Direct input Range 40A
External Sensor Range 10V
Sensor Ratio 10.0000mV/A
Scaling
Scaling Off
Scaling Item VT
VT 1.0000
CT 1.0000
Scaling Factor 1.0000
Sync Source
Element Object Element1 Element2 Element3
Sync Source I1 I2 I3
Filters
Line Filter Off
Freq Filter Off
Update Rate
Update Rate 500ms
Averaging
Averaging Off
Averaging Type Exp.
Exp. Count 2
Lin. Count 8
Integration
Integrator Status Reset condition
Integ Set
Mode Normal
Timer Setting 00000:00:00
Integ Start 2008/01/01 00:00:00
Integ End 2008/01/01 01:00:00
Auto Cal Off
WP±Type Charge/Discharge
qMode dc
Measure
S Formula Urms
*
Irms
S, Q Formula Type1
Phase 180 Lead/Lag
Sync Measure Master
