A - 12 DS457-XX20004ZZWW Fixed Mount Imager Integration Guide
Data Matrix Inverse 588 F1h 4Ch DS457-SR/HD/DL:
Regular
DS457-DP:
Inverse Autodetect
12-92
GS1 Data Matrix 1336 F8h 05h 38h Disable
12-93
Decode Mirror Images (Data Matrix
Only)
537 F1h, 19h Auto
12-94
Maxicode 294 F0h 26h Disable
12-95
QR Code 293 F0h 25h Enable
12-95
GS1 QR 1343 F8h 05h 3Fh Disable
12-96
MicroQR 573 F1h 3Dh Enable
12-96
Linked QR Mode 1847 737h Linked QR Only
12-97
Aztec 574 F1h 3Eh Enable
12-98
Aztec Inverse 589 F1h 4Dh Inverse Autodetect
12-98
Han Xin 1167 F8h 04h 8Fh Disable
12-99
Han Xin Inverse 1168 F8h 04h 90h Regular
12-99
Grid Matrix 1718 F8h 06h B6h Disable
12-100
Grid Matrix Inverse 1719 F8h 06h B7h Regular
12-100
Grid Matrix Mirrored 1736 F8h 06h C8h Non-Mirrored
12-101
Symbology-Specific Security Levels
Redundancy Level 78 4Eh 1
12-102
Security Level 77 4Dh 1
12-104
1D Quiet Zone Level 1288 F8h 05h 08h 1
12-105
Intercharacter Gap Size 381 F0h 7Dh Normal
12-106
Macro PDF
Macro PDF Transmit/Decode Mode
Symbols
188 BCh Passthrough Mode
12-108
Flush Macro PDF Buffer N/A N/A N/A
12-109
Abort Macro PDF Entry N/A N/A N/A
12-109
DL Parsing Parameters
Driver’s License Parsing N/A N/A No Driver’s License
Parsing
13-2
Table A-1
Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.
