1.4 Interface Diagram
The following figure shows a diagram of the interfaces of the microscope stand. The combination upper
stand part FL/HBO and lower stand part with HAL 50 illumination serves as demonstration.
The interfaces vary according to which upper or lower stand part has been chosen.
Legend of
284H284HFig. 1-3:
1 Tube
2 Achromatic illumination adapter
3 Upper stand part
4 Filter slider reflected light
5 Adjustment aid
6 Adapter
7 Reflector insert
8 Lower stand part
9 Filter slider transmitted light
10 Filter in the filter wheel transmitted light
11 Condenser carrier
12 Condenser
13 Stage carrier
14 Stage
