4.2 Operating and Functional Elements of Optional Components
4.2.1 Lower Stand Part for LED Transmitted Light Illumination
1 LED illumination (mounted on condenser carrier)
2 Cord guide to the connector socket for
LED illumination in the stand base
3 Focusing drive – fine adjustment (both sides)
4 Focusing drive – rough adjustment (both sides)
5 Light intensity control (both sides)
6 Power input with fuse compartment
7 Release tractor for vertical stop of focusing drive
8 On/off switch
Fig. 4-17 Lower stand part for LED transmitted light illumination
