Zeiss Axio Scope.A1 - Summary of the Controls and Functional Elements

INTRODUCTION
Axio Scope.A1 Summary of the Controls and Functional Elements Carl Zeiss
M60-2-0007 e 05/08 19
1.5 Summary of the Controls and Functional Elements
Legend of 285H285HFig. 1-4:
1 Eyepieces
2 Binocular tube part
3 Field diaphragm (non removable or as slider)
4 Adjustment aid (on upper stand part FL/HBO only)
5 Aperture diaphragm (non-removable or as slider) or FL attenuator
6 Reflected light lamp
7 Filter slider reflected light
8 Transmitted light lamp
9 Filter slider transmitted light
10 Gear shift for diffusion disk (for lower stand part with HAL 100 illumination only)
11 Focusing drive – fine adjustment (both ways)
12 Focusing drive – rough adjustment (both ways)
13 Light intensity control (operable from both sides)
14 Gear knob for adjusting the mechanical stage in direction X
15 Gear knob for adjusting the mechanical stage in direction Y
16 Gear knob for adjusting the condenser vertically (both sides)
17 Filter wheel six fold (operable from both sides, not available for lower stand part for LED illumination)
18 Centering screw for condenser (both sides)
19 Field diaphragm (not available for lower stand part for LED illumination)
20 Condenser with aperture diaphragm (with optional modulator disk)
21 Nosepiece
22 Reflector insert (changeable)
23 Gear shift for diffusion disk reflected light (not available on all upper stand parts)
24 On/off switch (not available on lower stand parts for HAL 100 illumination)
25 Release tractor for vertical stop on focusing drive
