ABB AC 800F

4 Cabling the AC 800F
4-93
Connection example: AC 800F with I/O units and internal termination
Fig. 4-71 CAN bus connection example, with internal termination
Fig. 4-72 FI 810F internal termination, channels 0, 1 and 2
When touching the terminating jumpers take the necessary ESD
protection measures. Follow the instructions given in Section 2.
