ABB AC 800F

5 AC 800F Functional Description
5-34
You can skip the error message by pressing the Esc key, and restart the 1
st
Stage
self-test. The message “
n times skipped“ indicates how often the error has already
been ignored. If the error cause still exists or another error should occur, an error
entry is written into the error memory, until the max. error count is reached.
The maximum error count has been reached: further operation rejected
!!! Please, contact service !!!
Once the error memory is full, further operation of the AC 800F is disabled. Please
contact the service in this case.
5.4.4 Configuring the Boot Loader
When the 1
st
Stage has been completed without any errors, the Boot Loaderis
started. If you should like to modify the Boat Loader configuration, the Run/Stop
switch must be in the Stop position.IntheRun position no user settings can be
made, and not all configuration messages are output. The EPROM version number
is shown in the Boot Loader header. When the Run/Stop switch is in the Stop
position, the current parameters are output after this. These parameters can be
modified by pressing any key during the waiting time to call the input menu.
ABB ** AC800F **
Fieldcontroller BootLoader V6.80
(C)1999 ABB Automation Products
17 May 2001 T.Guenther
Testing network connection 1 ... Ok
Testing network connection 2 ... Error: Controller or network problem: 80000386
------------------------------------------------------------------------------
CPU is i960HT [B0/B1] with 4 MByte RAM
System will startup in AUTO mode
First Network interface [00:C0:C9:10:00:88] - Cheapernet
- IP address: 172.16.1.1
- Subnet mask: 255.255.240.0
Second Network interface [00:C0:C9:10:00:A1] - Cheapernet
- IP address: 172.16.16.1
- Subnet mask: 255.255.240.0
Default router: 0.0.0.0
RTC-Time: 17.05.01, 00:05:13 local
------------------------------------------------------------------------------
To change these parameters, hit <SPACE> within 2 seconds
Fig. 5-19 Boot Loader system messages up to the key prompt
