ABB AC 800F

5 AC 800F Functional Description
5-30
5.4.1 Starting and setting up the MS-Windows NT 4.0 and MS-Windows 2000 terminal
emulation
MS-Windows NT 4.0 and MS-Windows 2000 include a HyperTerminal emulation.
After proper installation of MS-Windows NT 4.0 and MS-Windows 2000 it is available
in the Accessories program group. Click on the Start button of the task bar.
Selecting Programs →
→→
→ Accessories will then call up the HyperTerminal icon.
Clicking on the icon opens the HyperTerminal menu. The HyperTerminal program
icon and all available emulations are shown. First double-click on the HyperTerminal
icon to create a new emulation for Diagnosis.
Fig. 5-15 Creating a new emulation
In the next window you can set up a direct connection via your serial interface. The
appropriate serial interface (COM1, COM2 or other) to which the AC 800F is
connected must be selected under menu item Connect To for this.
