ABB AC 800F

8 Accessories
8-16
The clock is delivered in a 19" case and can be mounted on the same support rails as
the AC 800F. In the ordering example seen in the table above the clock is equipped
with an indoor antenna and a 10 m antenna cable. Under difficult receiving conditions
(e.g. in buildings made of reinforced concrete) it is recommended to use an outdoor
antenna with lightning protection module. Please contact the company Hopf for more
detailed information and the selection of the appropriate configuration for your appli-
cation. Figure 8-7 shows the radio clock dimensional drawing.
Fig. 8-7 Radio clock dimensions
8.3.3 Setting the radio clock
Read the technical documentation which the company Hopf de-
livers with the clock, and observe the information and the techni-
cal data given here.
