ABB AC 800F

3 Mounting the AC 800F
3-27
Several systems can be used on one system bus. Only nodes of the
same system can automatically interchange data. If, however, data are to
be transferred between systems, this must be configured under
Control Builder F. Then the data exchange will take place via write and
read utilities.
The time will be synchronized for all AC 800F and process stations,
independent of the system to which they belong.
Fig. 3-13 Standard setting
