ABB AC 800F

3 Mounting the AC 800F
3-5
3.1.2.1 Improved air circulation
Figure 3-4 shows the air flow in a
cabinet with one Freelance 2000
rack and one AC 800F.
The air flow passes through all
racks and is heated while
ascending.
Fig. 3-4 Air flow without air deflectors
