7 Functional Description of the Fieldbus Modules
7-15
Network topology Linear bus
Active bus termination at both ends. A total length of all
branches of up to 6.6 m is only permissible with
transmission rates ≤ 1.5 Mbit/s. No branches should be
used with 12 Mbauds
Medium Shielded twisted-pair cable
Number of stations 32 stations per segment without repeaters. Up to 127
stations possible with repeaters.
Connector plugs Preferably 9-pinSub-D connectors.
7.2.3.2 Cable parameters
The bus cable to be used for FI 830F is specified in DIN 19245/EN 50170 as line type
Aandcanbeusedaccordingtothefollowingtable:
Parameters Line A
Characteristic impedance in Ω
135 ... 165
Capacitance per unit length (pF/m) <30
Loop resistance (Ω/km)
110
Wire diameter (mm) 0.64
Cross-sectional area of wire (mm
2
) >0.34
From the parameters specified above result the following bus segment lengths.
Transmission rate in KBit/s 9.6 19.2 93.75 187.5 500 1500 12000
Range in m/segment 1200 1200 1200 1000 400 200 100
