13.1 DFC 02 - AC 800F naming conventions
Although the FieldController DFC 02 and AC 800F modules are identical except for
their differently colored front panels, their components have different names. The
cables and accessories are identical as well.
The following list gives you an overview:
DFC 02 AC 800F Function
DFA 01 AM 801F Battery module
DFA 02 AM 802F Debug module
DFA 007 TK 817F CAN cable, 80 ... 400 m
DFA 009 SY 809F Buffer battery holder
DFA 010 TK 802F Mains cable for 24 V DC power supply
DFA 011 TK 811F CAN cable, max. 80 m
DFA 021 TK 821F Link cable, serial, to terminal block, 0.5 m
DFA 031 TK 811F Link cable, CAN to terminal block, 0.5 m
DFA 047 TK 807F Mains cable, 115 - 230 V AC power supply, open end
DFA 048 TK 808F Mains cable, 115 - 230 V AC power supply, Europ. plug
DFA 655 RW 855F Special contact ledge for mounting outside a cabinet
DFA 656 RW 856F Mounting material for vibration-proof wall mounting
DFA 070 TK 870F Terminal block
DFA095 AM 895F Dummy panel for covering empty slots
DFC 02 PM 802F AC 800F basic unit, CPU board and housing
DFP 01 SA 801F 115 - 230 V AC power supply
DFP02 SD 802F 24 V DC power supply with red. supply
DFE 01 EI 801F Ethernet module, 10Base2
DFE 02 EI 802F Ethernet module, AUI
DFE 03 EI 803F Ethernet module, 10BaseT (twisted pair)
DFE 04 EI 804F Ethernet module, 100BaseTx
DFM 01 FI 830F Profibus module
DFM 02 FI 820F Serial module, 2 channels
DFM 03 FI 810F CAN module, 3 channels
DSU 08 SB 808F Battery
DSU 141 TK 890F Diagnostic cable, 10 m
TK 891F Diagnostic cable, 5 m
DSU 485 RY 885F Grounding strip, 0.3 m
