6. Electrical installation
6.1. Safety
Overview
The installation includes the following items:
– “6.3 Grounding the drive system” on page 119
– “6.4 Internal wiring” on page 121
– “6.5 Cable entry systems” on page 125
– “6.8 Auxiliary power, control and serial communication cables” on page 139
– “6.9 Heating cable” on page 155
Figure 6-1 Phase module on lift table
DANGER Hazardous voltage!
Improper work can result in life-threatening injury or DEATH!
– Only qualified personnel who are familiar with the site requirements,
equipment requirements and the relevant electrical codes can
perform the installation.
– DO NOT switch on the main and auxiliary power supplies during
the installation.
– After the installation, obtain permission from the ABB commissioning
personnel BEFORE switching on the the main and auxiliary
power supplies.
