MECHANICAL INSTALLATION
PRODUCT
ACS6000
DOCUMENT KIND
User manual
DOCUMENT ID.
3BHS212794 E01
REV.
N
LANG.
en
PAGE
87/266
5.3.5. Cable duct material
5.3.6. Installation material
Installation material is supplied with the drive in a separate box.
5.3.7. Tools
See “1.10 Tools” on page 30.
5.3.8. Floor preparation
See “Appendix C - Mechanical drawings”.
5.3.9. Floor fixation
The cabinet can be bolted or welded to the floor. For more information, see
“Appendix C - Mechanical drawings”.
5.3.10. Raw water circuit
The incoming and outgoing raw water pipes are connected to the flanges of the
WCU. Installation material such as counter-flanges, bolts, nuts and seals are
supplied. For information on dimensions of the raw water entry and the flanges,
see “Appendix C - Mechanical drawings”.
NOTICE Risk of component damage!
– Use cable ducts of non-flammable material with non-abrasive surface.
– To prevent dust, humidity and animals from entering the drive,
protect all cable entries and exits of cable ducts.
CAUTION Hazardous voltage!
– If you want to weld a cabinet to the floor, connect the earth clamp of
the welder to the PE ground busbar of the drive.
