OPERATION
PRODUCT
ACS6000
DOCUMENT KIND
User manual
DOCUMENT ID.
3BHS212794 E01
REV.
N
LANG.
en
PAGE
167/266
8.5.1. Operational settings
NOTE – The control panel is only used if an alarm or a fault condition must
be rectified.
After commissioning of the EXU, the control panel is set to remote, and local
operation is locked in parameter 16.04 LocLock. This setting prevents the control
panel being switched to local control unintentionally.
The actual values shown on the display can be freely selected. The following default
values are shown on the display when the panel is in local mode:
– Motor current in %
– Actual armature voltage in V
– Actual converter current in A (rectified AC current value)
When the control panel has been set to remote, the START / STOP keys become
inoperable.
8.5.2. Resetting alarm and fault messages
– Alarm messages: cannot be reset by pressing the reset soft key.
The alarm resets automatically as soon as the reason causing the alarm has
been resolved.
– Fault messages: must be reset manually after the reason causing the fault has
been resolved.
The message on the display can be reset either by pressing the reset soft key
on the EXU control panel, or by pressing the reset button on the control panel
of the drive.
NOTICE Risk of component damage!
DO NOT unlock local operation and switch the control panel to remote
while the drive is in operation!
– If you attempt to perform these actions, the drive shuts down
