MECHANICAL INSTALLATION
PRODUCT
ACS6000
DOCUMENT KIND
User manual
DOCUMENT ID.
3BHS212794 E01
REV.
N
LANG.
en
PAGE
86/266
5.3. General notes on installation
5.3.1. Dimensions and clearances
For information on dimensions, location and size of fixing holes and clearances,
see “Appendix C - Mechanical drawings”.
5.3.2. Access to the cabinets
Joining transport units and fitting the DC- busbar joints require rear and top
access.
5.3.3. Cabinet roof
5.3.4. Fire protection
To prevent fire from spreading into the drive, apply suitable fire protection
measures.
NOTICE Risk of component damage!
Observe the following during installation:
– Ensure that no dirt enters the drive. Always close the doors when work
is discontinued and completely cover openings. Metallic dust in
particular could cause failures when the drive is powered up and
cause damage.
– When joining two transport units, DO NOT damage or dislocate the
EMC sealing strip that is glued onto the outer joining surfaces of the
cabinet frame.
– If the transport units are joined but not yet on the base frame, do not
lift and move them with a crane. Instead, use appropriate transport
means, such as heavy load hydraulics rollers or air cushions.
NOTICE Risk of damage.
The cabinet roof is not designed as a base for foreign devices or
cable ducts.
– DO NOT install any foreign objects on the roof and do not step
on roof.
