TRANSPORTATION, STORAGE AND DISPOSAL
PRODUCT
ACS6000
DOCUMENT KIND
User manual
DOCUMENT ID.
3BHS212794 E01
REV.
N
LANG.
en
PAGE
81/266
Figure 4-2 Lift frame (A) and lift spreader (B)
1) Safety hook
2) Lift frame
3) Strap
4) Protect the edges, door handles and levers
5) Safety hook or shackle
6) Lifting bracket
7) Slope angle (maximum 15°)
8) Lift spreader
A
1
2 2
3
4
5
6
B
1
3
4
5
6
7
8 8
