Specicaons
i-STAT Alinity Instrument Specicaons
Dimensions: Height x Width x Depth 10.1 in (25.6 cm) x 5.6 in (14.3 cm) x 3.2 in (8.1 cm)
Weight 1.5 lb (660 g) without baery
1.9 lb (840 g) with baery
Operaonal range: Temperature and
humidity
16 to 30ºC (61 to 86ºF) for clinical tesng
10 to 90% non-condensing relave humidity, with
maximum saturaon temperature of 34ºC (93.2ºF)
Tesng Environment Indoors, on a dry, clean, horizontal, stable surface.
Avoid nearby vibraon equipment such as centrifuges.
Avoid direct sunlight.
Altude up to 3,048 meters (10,000 feet)
Storage range: Temperature and humidity -10 to 60ºC (14 to 140ºF)
10 to 90% non-condensing, with maximum saturaon
temperature of 50ºC (122ºF)
Display 5 in, 800 x 480 pixels with touchscreen, measured
diagonally
Power source Lithium Ion Rechargeable Baery, 3.65 (nominal) VDC,
19.3 Wh
Exterior materials No natural or synthec rubber latex is used anywhere on
the exterior of this product, the product packaging, or the
accessories.
Wireless Labeling
The i-STAT Alinity instrument includes the FCC mark and FCC module idener.
Table 1–1: Wireless specifications for the i-STAT Alinity instruments
Wireless
Characterisc i-STAT Alinity Instrument
Network Standard IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (1-stream)
Maximum RF Power 200 mW
Typical Maximum SAR 765 mW/kg at 0 cm
Wireless QoS requirements None. Best-eort delivery service is sucient.
