260 Appendix D
Initial Settings
Initial Settings, Settings that can be Saved/Recalled, Settings that can be
Backed Up
NOTE The OPEN/SHORT/LOAD compensation data and the LOAD standard definition settings
for multi-compensation are not reset regardless of the resetting method used.
Multi
compensation
ON/OFF OFF No effect OFF lm
Channel number 0 No effect 0 lm
LOAD standard definition method
(Single/Multi)
Single No effect Single lm
Data transfer format ASCII ¬¬´´
Data buffer
Feeding target parameter None ¬¬´´
Control (feed/not feed) Not feed ¬¬´´
Size
Buffer 1 or Buffer 2 200 ¬¬´´
Buffer 3 1000 ¬¬´´
Comparator
ON/OFF OFF ¬¬lm
Limit range
ON/OFF
BIN1 ON ¬¬lm
BIN2 to BIN9 OFF ¬¬lm
Secondary parameter ON ¬¬lm
Limit range
setting
Upper limit value 0 ¬¬lm
Lower limit value 0 ¬¬lm
Limit range designation
method (mode selection)
ABS ¬¬lm
Reference (nominal) value 0 ¬¬lm
AUX BIN ON/OFF OFF ¬¬lm
Low C reject
ON/OFF OFF ¬¬lm
Limit value 0% ¬¬lm
BIN count
ON/OFF OFF ¬¬lm
Count value 0 ¬¬´´
Measurement signal level
monitor
Current OFF ¬¬lm
Vo l t a g e O F F ¬¬lm
Display
ON/OFF ON ¬¬lm
Number of digits 6 ¬¬lm
Fixed point
display
ON/OFF OFF ¬¬lm
Value of the
highest digit
(Msd)
Primary
parameter
1 nF ¬¬lm
Secondary
parameter
1 ¬¬lm
Deviation
measurement
mode
ON/OFF OFF ¬¬lm
Mode DEV ¬¬lm
Reference value 0 ¬¬lm
Page number of instrument setup display area 1 ¬¬lm
Key lock ON/OFF OFF No effect OFF ´´
Beeper
ON/OFF ON ¬¬lm
Mode FAIL ¬¬lm
Standard event status enable register value 0 No effect ¬´ ´
Service request enable register value 0 No effect ¬´ ´
Operation status enable register value 0 ¬¬´´
GPIB address 17 No effect ¬´ l
Table D-1 Initial settings, settings that can be saved/recalled, settings that can be backed up
Setting items
Initial settings
(factory settings)
Reset
Save/
Recall
Backup
Front panel key
(:SYST:PRES)
*RST
