4268A vs. 4288A GPIB Command Correspondence Table
4268A vs. 4288A GPIB Command Correspondence Table
G. 4268A vs. 4288A
GPIB Command
Correspondence Table
Compensation Entire compensation set ON/OFF :CORR N/A The 4268A turns on/off
all types of
compensation. (Only
the LOAD
compensation can be
turned on/off
separately.)
The 4288A turns on/off
OPEN/SHORT/LOAD
compensation
individually.
OPEN compensation ON/OFF N/A :CORR:OPEN
SHORT compensation ON/OFF N/A :CORR:SHOR
LOAD compensation ON/OFF :CORR:COLL:METH :CORR:LOAD
LOAD
standard
definition
Value setup :CORR:CKIT:STAN3
←
Definition parameter
setup
:CORR:CKIT:STAN3:FORM ←
Compensation
data
Measurement :CORR:COLL ←
setup and read out :CORR:DATA ←
Offset compensation ON/OFF N/A :CORR:OFFS The 4268A does not
support the offset
compensation.
Offset compensation data setup N/A :CORR:OFFS:DATA
Scanner (multi
compensation)
ON/OFF :CORR:MULT
←
Channel setup :CORR:MULT:CHAN ←
LOAD standard definition method
setup
:CORR:MULT:CKIT:STAN3 ←
Trigger Triggers a measurement :TRIG, *TRG ←
Trigger mode setup :TRIG:SOUR ←
Trigger delay time setup :TRIG:SEQ2:DEL :TRIG:DEL
Trigger
system
Resets :ABOR
←
Initiates :INIT ←
Continuous activation
ON/OFF
:INIT:CONT ←
Measured data
output
Data transfer format setup :FORM ← The 4288A also
controls data transfer
format of compensation
data.
Data readout Measurement result :FETC?, :READ?
←
Data buffer :DATA? {BUF1|BUF2} ← The 4288A can also use
BUF3.
Measurement signal
monitor result
:DATA? {IMON|VMON}
←
Data buffer
setup
Feeding target
parameter
:DATA:FEED ←
Control (feed/not feed) :DATA:FEED:CONT ←
Buffer size :DATA:POIN ←
Table G-1 At-a-glance GPIB command correspondence between 4268A and 4288A (by
function)
Function Item to Be Set Up/Executed
GPIB command
Note
4268A 4288A
