4268A vs. 4288A GPIB Command Correspondence Table
4268A vs. 4288A GPIB Command Correspondence Table
Comparator ON/OFF :CALC:COMP ←
Limit range reset N/A :CALC:COMP:CLE
Primary
parameter
limit range
setup
ON/OFF :CALC:COMP:PRIM:BIN{1-9}:
STAT
←
Lower/Upper Limit
value
:CALC:COMP:PRIM:BIN{1-9} ←
Limit range designation
method (mode
selection)
:CALC:COMP:MODE ←
Reference (nominal)
value
:CALC:COMP:PRIM:NOM ←
Secondary
parameter
limit range
setup
ON/OFF :CALC:COMP:SEC:STAT ←
Lower/Upper Limit
value
:CALC:COMP:SEC:LIM ←
AUX BIN function ON/OFF :CALC:COMP:AUXB ←
Low C reject
function
ON/OFF N/A :CREJ The 4268A does not
support the Low C
reject function.
Limit value setup N/A :CREJ:LIM
BIN count
function
ON/OFF :CALC:COMP:COUN
←
Resets all count values :CALC:COMP:COUN:CLE ←
Readout of count values :CALC:COMP:COUN:DATA? ←
Readout of count value
of overload
N/A :CALC:COMP:COU
N:OVLD?
The 4268A cannot
count overload.
Readout of count values
for each channel
N/A :CALC:COMP:COU
N:MULT:DATA?
The 4268A cannot
count for each channel.
Readout of count value
of overload for each
channel
N/A :CALC:COMP:COU
N:MULT:OVLD?
Measurement
signal monitor
Current
monitor
ON/OFF :CALC3:MATH:STAT
←
Monitor value readout :DATA? IMON ←
Voltage
monitor
ON/OFF :CALC4:MATH:STAT ←
Monitor value readout :DATA? VMON ←
Save/Recall Save *SAV ←
Recall *RCL ←
Table G-1 At-a-glance GPIB command correspondence between 4268A and 4288A (by
function)
Function Item to Be Set Up/Executed
GPIB command
Note
4268A 4288A
