64 Chapter 6
Reading Out Measured Result
Reading Out Measured Result
The program of Example 6-2 is detailed below.
Lines 50 to 60 Sets the GPIB address.
Line 70 Sets the data transfer format to the binary format.
Lines 90 to 100 Turns ON the trigger system continuous startup and sets the trigger
mode to the GPIB trigger.
Lines 120 to 130 Reads out the ON/OFF state of the comparator function and assigns it
to the Comp_flag variable.
Lines 170 to 210 After the trigger system state transitions to the trigger wait state,
triggers the instrument.
Lines 220 to 250 Reads out the header part.
Line 270 If the Comp_flag value is 1 (the comparator function is ON), reads out
the measurement status, measured primary parameter result, measured
secondary parameter result, and comparator sorting result.
NOTE Binary data must be read out without formatting. Therefore, use an I/O path (@Binary) set
up for such readout. This is also applicable to Line 290.
Line 290 If the Comp_flag value is not 1 (the comparator function is OFF),
reads out the measurement status, measured primary parameter result,
and measured secondary parameter result.
Line 310 Reads out the message terminator at the end of the data.
Lines 350 to 370 Displays the measurement status, measured primary parameter result,
and measured secondary parameter result.
Line 390 If the Comp_flag value is 1 (the comparator function is ON), displays
the comparator sorting result.
Line 410 If the Comp_flag value is not 1 (the comparator function is OFF),
displays “Comparator : OFF.”
