Lesson 2 – Waveform Digitizer Setup with the Analog Setup Tool
169
Contents of an Analog Set
Analog Signal Routing
This is a read-only display provided by the Analog Setup Tool,
based on the current routing setup. It shows the setting of the
module’s relay multiplexer switches. This hardware monitor
function is especially useful for debugging purposes.
The relay multiplexers of the analog modules can be set by means
of the Routing Tool.
