Agilent Technologies 93000 SOC Series User Manual

Lesson 1 – Analog Modules
63
Table 1 High Resolution AWG (WGA) Key Specifications
Table 2 30M AWG (WGE) Key Specifications
Specification Value
Sampling rate 8 ksps to 1.024 Msps
Resolution 18-bit
Pin counts per module 8 single-ended (4 parallel test) or
4 differential (2 parallel test)
Waveform Memory 4 M
Max sinewave fre-
quency
250 kHz
Output Range 6 Vpp @600 ohm load
DC offset Range ±5 V @600 ohm load
Output Impedance 50 ohm
Filter Through, 1.3 kHz, 13 kHz, 130 kHz, 300 kHz
Specification Value
Sampling rate 8 ksps to 30 Msps
Resolution 16-bit
Pin counts per module 8 single-ended (4 parallel test) or
4 differential (2 parallel test)
Number of AWG cores
per module
2
Waveform memory 4 M (per AWG core)
Max. sinewave frequency 7.5 MHz
Output range 2.5 Vpp @ 50 ohm load
(0 to 70 dB attenuation with 0.01 dB resolution)
DC offset range ±2.5 V @ 50 ohm load to GND
-2.5 V < AC+DC < 2.5 V @ 50 ohm load to GND
Output impedance 50 ohm
Filter Through, 1.3 kHz, 150 kHz, 500 kHz, 1.4 MHz
