Agilent Technologies 93000 SOC Series User Manual

Lesson 1 – Analog Modules
64
Table 3 High Speed AWG (WGB) Key Specifications
Table 4 500M AWG (WGD) Key Specifications
Specification Value
Sampling rate 8 ksps to 128 Msps
Resolution 12-bit
Pin counts per module 8 single-ended (4 parallel test) or
4 differential (2 parallel test)
Waveform Memory 2 M
Output Range 2.5 Vpp @50 ohm load
DC offset Range ±2.5 V @ 50 ohm load to GND
-2.5 V < AC+DC < 2.5 V @ 50 ohm load to GND
Max sinewave fre-
quency
32 MHz
Output Impedance 50 ohm
Filter Through, 1.3 MHz, 6.1 MHz, 13 MHz, 41.6 MHz
Specification Value
Sampling rate 8 ksps to 500 Msps
Resolution 12-bit
Pin counts per module 8 single-ended (4 parallel test) or
4 differential (2 parallel test)
Waveform memory 8 M
Output range 2.5 Vpp @ 50 ohm load
(0 to 50 dB attenuation with 0.01 dB resolution)
DC offset range ±2.5 V @ 50 ohm load to GND
-2.5 V < AC+DC < 2.5 V @ 50 ohm load to GND
Max. sinewave frequency 125 MHz
Output impedance 50 ohm
Filter Through, 1.3 MHz, 3.8 MHz, 13 MHz, 42 MHz, 78 MHz,
163 MHz
