Agilent Technologies 93000 SOC Series User Manual

Lesson 1 – Analog Modules
65
Table 5 Ultra High Speed AWG (WGC) Key Specifications
Table 6 4.1G AWG (WGF) Key Specifications
Specification Value
Sampling rate 50 ksps to 2.6 Gsps
Resolution 8-bit
Pin counts per module 4 single-ended or 2 differential
Waveform Memory 8 M
Output Mode Differential
Max sinewave fre-
quency
(characteristic data) 300 MHz @-3 dB
Output Range 2 Vpp@50 ohm (Normal mode)
1 Vpp@50 ohm (Direct mode)
DC offset Range ±1.0 V (Normal mode only)
AC + DC ±2.0 V (Normal mode)
Output Impedance 50 ohm
Filter Through, 20 MHz, 50 MHz,100 MHz, 200 MHz
Specification Value
Sampling rate 25 Msps to 4.1 Gsps
Resolution 8-bit
Pin counts per module 4 single-ended (4 parallel tests) or
4 differential (4 parallel tests)
Waveform memory 16 M
Output Mode Differential
Max. sinewave frequency 800 MHz @-3 dB
(characteristic data) 1.2 GHz @-10 dB
Output range 1 Vpp @ 50 ohm load (2 Vpp differential)
Output impedance 50 ohm
