Configuring Spanning Tree Parameters Sample MST Region Configuration
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 6-47
3 Map VLANs 100 and 200 to MSTI 2 and VLANs 300 and 400 to MSTI 4 using the spantree msti
vlan command to define the configuration digest. For example:
-> spantree msti 2 vlan 100 200
-> spantree msti 4 vlan 300 400
See the “Sample MSTI Configuration” on page 6-48 for a tutorial on how to create and map MSTIs to
VLANs.
4 Configure 3 as the maximum number of hops for the region using the spantree mst region max-hops
command. For example:
-> spantree mst region max-hops 3
Note. (Optional) Verify the MST region configuration on each switch with the show spantree mst
command. For example:
-> show spantree mst region
Configuration Name = ALE Marketing,
Revision Level = 2000,
Configuration Digest = 0x922fb3f 31752d68 67fe1155 d0ce8380,
Revision Max hops = 3,
Cist Instance Number = 0
All switches configured with the exact same values as shown in the above example are considered members
of the ALE Marketing MST region.
