Configuring IP Tunneling
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 15-38
Configuring a Tunnel Interface
To configure a GRE tunnel, use the ip interface tunnel command as shown:
-> ip interface "gre" tunnel source 23.23.23.1 destination 155.2.2.2 protocol gre
In this example, the GRE tunnel named “gre” is created and assigned a source IP address of 23.23.23.1
and a destination IP address of 155.2.2.2.
You can configure an IP address for the GRE tunnel interface using the ip interface command as shown:
-> ip interface "gre" address 24.24.24.1 mask 255.255.255.0
To configure an IPIP tunnel, use the ip interface tunnel command as shown:
-> ip interface "ipip" tunnel source 23.23.23.1 destination 155.2.2.2 protocol
ipip
In this example, the IPIP tunnel named “ipip” is created and assigned a source IP address of 23.23.23.1
and a destination IP address of 155.2.2.2.
You can configure an IP address for the IPIP tunnel interface using the ip interface command as shown:
-> ip interface "ipip" address 24.24.24.1 mask 255.255.255.0
Notes.
• An interface can be configured only as a VLAN or a Tunnel interface.
• To display information about the configured tunnels on the switch, use the show ip interface
command.

Alcatel-Lucent OmniSwitch 6860 Series Specifications

General

Model	OmniSwitch 6860 Series
Category	Switch
Maximum Ports	48
Switching Capacity	Up to 176 Gbps
Operating System	AOS (Alcatel-Lucent Operating System)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
Port Types	10/100/1000BASE-T, SFP+, QSFP+
Ports	24, 48
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Form Factor	1U rack-mountable
MAC Address Table Size	32, 000
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 mm x 420 mm x 44 mm (17.3 in x 16.5 in x 1.73 in)
Power Supply	AC or DC (depending on model)
Power Consumption	Varies by model and configuration
