Configuring Static Link Aggregation Configuring Static Link Aggregation Groups
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 8-7
Creating and Deleting a Static Link Aggregate Group
The following subsections describe how to create and delete static link aggregate groups with the linkagg
static agg size command.
Creating a Static Aggregate Group
To create a static aggregate group on a switch, enter linkagg static agg followed by the user-specified
aggregate number, size, and the number of links in the static aggregate group:
For example, to create static aggregate group 5 that consists of eight links, on a switch, enter:
-> linkagg static agg 5 size 8
As an option you can also specify a name and/or the administrative status of the group by entering linkagg
static agg followed by the user-specified aggregate number, size, the number of links in the static
aggregate group, name, the optional name, admin-state, and either enable or disable (the default is
enable).
For example, to create static aggregate group 5 called “static1” consisting of eight links that is
administratively disabled enter:
-> linkagg static agg 5 size 8 name static1 admin-state disable
Deleting a Static Aggregate Group
To delete a static aggregation group from a switch use the no form of the linkagg static agg size
command by entering no linkagg static agg followed by the number that identifies the group. For
example, to remove static aggregate group 5 from the switch configuration, enter:
-> no linkagg static agg 5
Adding and Deleting Ports in a Static Aggregate Group
The following subsections describe how to add and delete ports in a static aggregate group with the
linkagg static port agg command.
Adding Ports to a Static Aggregate Group
The number of ports assigned in a static aggregate group can be less than or equal to the maximum size
you specified in the linkagg static agg size command. To assign a port to a static aggregate group you use
Note. The number of links assigned to a static aggregate group must always be close to the number of
physical links that you plan to use. For example, if you are planning to use 2 physical links you should
create a group with a size of 2 and not 4 or 8.
Note. If you want to specify spaces within a name for a static aggregate group the name must be specified
within quotes (for example, “Static Aggregate Group 5”).
Note. You must delete any attached ports with the linkagg static port agg command before you can delete
a static link aggregate group.
