Configuring QoS QoS Policy Overview
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 26-30
Policy Conditions
The following conditions are supported and can be combined with other conditions and/or actions:
The CLI prevents you from configuring invalid condition combinations that are never allowed; however, it
does allow you to create combinations that are supported in some scenarios. For example, you might
configure source ip and a destination ip for the same condition.
Consider the following guidelines when configuring policy conditions:
• IPv4 and IPv6 conditions cannot be combined.
• The destination VLAN condition is only supported in multicast policy rules.
• IP multicast traffic (not IGMP) is treated as regular traffic; QoS functionality works the same way with
this type of traffic, with the exception that the destination port condition does not apply.
• The IP multicast condition works in combination with Layer 1, Layer 2, and Layer 3 destination
conditions only if these conditions specify the device that sends the IGMP report packet.
• Source and destination parameters can be combined in Layer 2, Layer 3, and Layer 4 conditions.
• In a given rule, ToS or DSCP can be specified for a condition with priority specified for the action.
• Individual items and their corresponding groups cannot be combined in the same condition. For
example, a source IP address cannot be included in a condition with a source IP network group.
• The Layer 1 destination port condition only applies to bridged traffic, not routed traffic. In addition, the
destination port condition only applies to unicast bridged traffic, not multicast or broadcast traffic.
• Layer 2 and Layer 3 rules are always effected on bridged and routed traffic. As a result, combining
source or destination TCP/UDP port and IP protocol in a condition is allowed.
For specific information about how to configure policy conditions and actions to create a policy rule, see
“Creating Policies” on page 26-42.
Supported Policy Conditions Table
Layer 1 Layer 2 Layer 3
destination port
destination port group
source port
source port group
source MAC
source MAC group
destination MAC
destination MAC group
802.1p
inner 802.1p
ethertype
source VLAN
inner source VLAN
destination VLAN (multicast rules only)
IP protocol
source IP
multicast IP
destination IP
source network group
destination network group
multicast network group
ToS, DSCP
ICMP type, ICMP code
source IPv6
destination IPv6
IPv6 traffic
IPv6 flow label (FL)
Layer 4 IP Multicast (IGMP)
source TCP/UDP port
destination TCP/UDP port
service, service group
TCP flags
(ECN/CWR are not supported)
destination only
