Configuring Ethernet Ports Configuring Ethernet Port Parameters
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 1-12
LED Color and Mode Settings
• LED Color - The color of the LED can be changed to yellow, white, red, magenta, green, blue, aqua, or
off.
• Activity Mode - The LED will blink normally based on the port activity but the color of the LED can
be changed.
• Solid Mode - The LED will not blink based on the port activity, it will always be solid. The color of
the LED can be changed.
-> interfaces 1/1/30 beacon admin-status enable
-> interfaces 1/1/30 beacon led-color magenta
-> interfaces 1/1/30 beacon led-mode solid
Beacon settings are saved and can be administratively enabled or disabled as needed at a later time. This
allows administrators to reuse previously configured LED settings without having to start over. Use the
show interfaces beacon command to view the beacon settings.
-> show interfaces beacon
Ch/Slot/Port Admin-Stat LED-Color LED-Mode
------------+-------------+--------------+------------
1/1/1A Disable Magenta Solid
1/1/2A Disable Blue Activity
1/1/30A Enable Magenta Solid
1/1/31A Enable Off Solid
Note. The beacon LED feature does not affect the normal behavior of switch ports or traffic flow. It only
sets LED colors and behaviors for the uses listed above. If an actual alarm or issue is detected on the switch,
important LED status information related to the issue takes precedence and overrides beacon settings.
Note. The beacon LED feature is not supported on sub-ports 'b', 'c', or 'd' when an interface is operating in
4X10G mode. Additionally, only Solid mode is supported on sub-port 'a' for 4X10G interfaces.
