Configuring Access Guardian Access Guardian Overview
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 28-24
Binding Classification Rules for UNP Profiles
The port and domain ID classification rules can be combined with other classification rules to create a
binding rule. The following binding rule combinations are supported and are listed in the order of
precedence:
1 Port + MAC address + IP address
2 Port + MAC address
3 Port + IP address
4 Domain ID + MAC address + IP address
A device must match all the rules specified in the binding rule combination. For example, if a binding rule
specifies a port, MAC address, and IP address, then the device must have a matching port, source MAC
address, and source IP address.
Extended Classification Rules for UNP Profiles
An Extended classification rule defines a list of individual rules and assigns the list a name and a
precedence value. A device must match all of the rules specified in the extended rule list.
4. Domain ID Packet is learned on a port or link aggregate that is assigned to a matching
domain ID.
5. MAC address + VLAN
tag
Packet contains a matching source MAC address and a matching VLAN ID
tag.
6. MAC address Packet contains a matching source MAC address.
7. MAC OUI + VLAN tag Packet contains a source MAC address with a matching OUI and a matching
VLAN ID tag.
8. MAC OUI Packet contains a source MAC address with a matching OUI.
9. MAC address range +
VLAN tag
Packet contains a source MAC address that falls within a specified range of
MAC addresses and a matching VLAN ID tag.
10. MAC address range Packet contains a source MAC address that falls within a specified range of
MAC addresses.
11. LLDP for media
endpoint devices
LLDP TLVs from an IP phone or from an OmniAccess Stellar Access Point
(AP) are detected.
12. Authentication Type +
VLAN tag
Packet received from a device authenticated through the matching
authentication type and the packet contains a matching VLAN ID tag.
13. Authentication Type Packet received from a device authenticated through the matching
authentication type.
14. IP address + VLAN
tag
Packet contains a matching source IP address and a matching VLAN ID tag.
15. IP address Packet contains a matching source IP address.
16. VLAN tag Packet contains a matching VLAN ID tag.
Note. Binding classification rules take precedence over individual classification rules.
Precedence Step/Rule Matching Condition
