Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 139
Parameter Descriptions Chapter 2
Line Voltage Negative Sequence Filter Time
Linear Number: P163
Default Value: 10 ms
Minimum Value: 0 ms
Maximum Value: 32767 ms
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter sets the time for the Line Voltage Negative Sequence Filter.
Line Voltage Negative Sequence Fault Threshold
Linear Number: P164
Default Value: 20.00%
Minimum Value: 0.00%
Maximum Value: 199.99%
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter sets the threshold for the Line Voltage Negative Sequence Fault.
Line Voltage Negative Sequence Fault Delay
Linear Number: P165
Default Value: 10 ms
Minimum Value: 0 ms
Maximum Value: 32767 ms
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter sets the delay for the Line Voltage Negative Sequence Fault.
Line Voltage Phaser Sequence Reverse Enable
Linear Number: P166
Default Value: 0
Minimum Value: 0
Maximum Value: 1
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter is used to enable or disable the Line Voltage Phaser Sequence
Reverse function. This changes the phase direction of the input voltage. The
phaser sequence is obtained from register K101. The sequence is positive if the
value of K101 is positive, and vice versa. If the sequence is negative, set this
parameter to “1”.
Value Description
0 Disable Line Voltage Phaser Sequence Reverse
1 Enable Line Voltage Phaser Sequence Reverse
