S331L UG PN: 10580-00321 Rev. M 3-55
Cable and Antenna Measurements 3-11 Freq/Dist Menu
Freq/Dist Menu (Continued)
Key Sequence: Freq/Dist
DTF Setup:
Cable List: The Cable List submenu key opens a list
of available cable specifications (Figure 3-11). Using
Up/Down arrow keys, the rotary knob, or the
touchscreen, select the desired cable and press Enter.
Note: When a cable is selected from this list,
propagation velocity and cable loss are automatically
set by the instrument. If the preselected values for
propagation velocity or cable loss are changed, the
analyzer will use “NONE” as the cable type.
Cable Loss: Press the Cable Loss submenu key and
enter the loss in dB/ft or dB/m for the selected cable
using the keypad, Up/Down arrow keys, or the rotary
knob and press Enter.
Prop Velocity: Press the Prop Velocity submenu key
and enter the applicable propagation velocity for the
selected cable using the keypad, Up/Down arrow keys,
or the rotary knob and press Enter.
Windowing: Opens the “Windowing Menu”
on page 3-56.
Figure 3-43. Frequency/Distance Menu (2 of 2)
Cable List
Cable Loss
DTF Setup
Prop Velocity
Windowing
Nominal Side
Lobe
d
owin
g
inal Sid
e
Lobe
