Anritsu Site Master S331L - Ethernet Configuration Menu

9-22 PN: 10580-00321 Rev. M S331L UG
9-8 System Menu System Operations
Ethernet Configuration Menu
Key Sequence: System (8) > Connectivity > Ethernet Configuration
Ethernet
Type: Press this key to select the type of IP Address
setting: DHCP or Static. When set to DHCP, the
instrument dynamically sets the IP Address and displays
it, as shown in Figure 9-22. When set to Static, the user
must manually enter the IP, Gateway, and Subnet
addresses, as shown in Figure 9-23. The settings are
saved once the Enter button is pressed.
Figure 9-21. Ethernet Configuration Menu
Figure 9-22. Ethernet Configuration Dialog - DHCP
Figure 9-23. Ethernet Configuration Dialog - Static
Enter
Ethernet
Type
En
te
r
Ty
p
e
DHCP Static
