Anritsu Site Master S331L User Manual

6-32 PN: 10580-00321 Rev. M S331L UG
6-17 Limit Menu High Accuracy Power Meter
6-17 Limit Menu
Key Sequence: Limit or Limit (6)
6-18 Sweep Menu
This menu is not available in High Accuracy Power Meter measurement
mode.
Limit: Turns the limits On or Off.
Fwd Upper Value: Sets the forward measurement
upper limit (displayed as red hash marks). Enter the
desired number by using the keypad, the rotary knob,
or the Up/Down arrow keys. If the keypad was used to
enter new values, press Enter to set the new setting or
press the Esc button to restore the previous setting.
Fwd Lower Value: Sets the forward measurement
lower limit (displayed as red hash marks). Enter the
desired number by using the keypad, the rotary knob,
or the Up/Down arrow keys. If the keypad was used to
enter new values, press Enter to set the new setting or
press the Esc button to restore the previous setting.
Rev Upper Value: Sets the reverse measurement
upper limit. Enter the desired number by using the
keypad, the rotary knob, or the Up/Down arrow keys. If
the keypad was used to enter new values, press Enter
to set the new setting or press the Esc button to restore
the previous setting.
Rev Lower Value: Sets the reverse measurement
lower limit. Enter the desired number by using the
keypad, the rotary knob, or the Up/Down arrow keys. If
the keypad was used to enter new values, press Enter
to set the new setting or press the Esc button to restore
the previous setting.
Figure 6-29. High Accuracy PM (MA24105A) Limit Menu
Limit
Limit
L
imi
t
On O
Fwd
Upper Value
Fwd
Lower Value
Rev
Upper Value
Rev
Lower Value
