S331L UG PN: 10580-00321 Rev. M 2-9
Instrument Overview 2-4 Front Panel Overview
ESC Key
Press this key to cancel any setting that is currently being made or to
close the currently dialog box.
Enter Key
Press this key to finalize data input or select a highlighted item from a
list.
Arrow Keys
The four arrow keys (around the Enter key) are used to scroll up, down,
left, or right. The Up/Down arrow keys can often be used to change a
value or to change a selection from a list. This function is similar to the
function of the rotary knob. The Left/Right arrow keys can be used to
move markers and the Up/Down arrow keys can also be used to move
limit lines.
In Video Inspection Probe (VIP) mode, use the arrow keys to pan a
captured image. Refer to Chapter 12.
Number Keypad
The Number keypad has two functions: The primary function is number
entry. The secondary function of the number keypad is to list various
menus. See “Keypad Menu Keys (1 to 9)”.
Rotary Knob
Turning the rotary knob changes numerical values, scrolls through
selectable items from a list, and moves markers or limit lines. In VIP
mode, use the rotary knob to zoom in and out on a captured image.
Keypad Menu Keys (1 to 9)
Not all Menus are active in various measurement modes. If any one of
these menus is available in a specific instrument mode of operation,
then it can be called from the number keypad. It may also be available
from a main menu key or a submenu key (Table 2-1 on page 2-10).
