S331L UG PN: 10580-00321 Rev. M 12-13
Video Inspection Probe (VIP) 12-5 VIP Menus
Measurement Menu
Key Sequence: Measurement
Live: In Live mode, the instrument displays a live view of
the connector endface. Use the control on the probe to
adjust the focus. The image cannot be panned or zoomed
until it is captured.
Captured: Press this submenu key to capture the
currently displayed image, which you may then zoom and
pan, using the rotary knob and arrow keys. The message
“File Not Saved” is displayed at the top of the screen until
you save the image and/or the measurement results.
Analyze: Press this submenu key to start analysis of the
VIP image. The overall Pass/Fail result is displayed in the
lower left corner of the screen. If the Results Table setting
is Auto, a table showing detailed results of the VIP test is
also displayed.
Results Table Auto/Off: This submenu key toggles on
and off the table of detailed VIP test results. When set to
Auto, the table will appear only when there are analysis
results to display.
Overlay On/Off: Press this submenu key to turn on and
off the colored circles showing the analysis areas and to
highlight any scratches and defects on the connector
endface:
Green – Unimportant scratches and contaminations
Red – Serious scratches and contaminations that
may impact signal quality
Zoom Control Help: Press this submenu key to display a
Help message with instructions on how to zoom and pan
the image. Press Dismiss to close the message box.
Figure 12-13.VIP Measurement Menu
Captured
Live
Analyze
Measurement
Results Table
Resu
ts Ta
Over
a
Contro
el
To Next Page
