Anritsu Site Master S331L User Manual

3-54 PN: 10580-00321 Rev. M S331L UG
3-11 Freq/Dist Menu Cable and Antenna Measurements
3-11 Freq/Dist Menu
Key Sequence: Freq/Dist
Frequency:
Start Frequency (F1): Press the Start Frequency (F1)
submenu key and enter the desired frequency using
the Up/Down arrow keys, the rotary knob, or the
keypad. Press Enter to complete the entry or if
entering a frequency using the keypad, press the
appropriate units key.
Stop Frequency (F2): Press the Stop Frequency (F2)
submenu key and enter the desired frequency using
the Up/Down arrow keys, the rotary knob, or the
keypad. Press Enter to complete the entry or if
entering a frequency using the keypad, press the
appropriate units key.
Distance:
Start Distance (D1): Press the Start Distance
submenu key and enter the desired distance using the
Up/Down arrow keys, the rotary knob, or the keypad.
Press Enter to complete the entry or if entering a
distance using the keypad, press the appropriate units
key.
Stop Distance (D2): Press the Stop Distance
submenu key and enter the desired distance using the
Up/Down arrow keys, the rotary knob, or the keypad.
Press Enter to complete the entry or if entering a
distance using the keypad, press the appropriate units
key.
Units: Press the Units key to toggle distance units
between meters and feet.
DTF Aid: Opens the DTF Aid dialog box (Figure 3-10).
This interactive parameter box allows setting multiple
parameters and displays maximum testing distance
and resolution.
Figure 3-42. Frequency/Distance Menu (1 of 2)
Freq/Dist
Frequency
DTF Aid
Units
D
D
D
DT
T
T
F
Ai
d
Un
it
s
mft
Stop Distance
(D2)
Start Distance
(D1)
Stop
Frequency
(F2)
Start
Frequency
(F1)
Distance
