Anritsu Site Master S331L User Manual

S331L UG PN: 10580-00321 Rev. M 4-7
Classic Mode Operation 4-2 Marker Menu
Marker Menu (Continued)
Key Sequence: Marker > M1
Marker
M 1 (On Off): Press this key to turn OFF the
selected marker (M1 to M6).
Edit: Press this key to enter a marker value.
Type (Ref Delta): Press this key to toggle the
marker type between Reference and Delta. This key
is displayed for markers M2 through M4 only. Marker
M1 is a Reference marker only.
Marker to Peak: Press this key to set a Marker
(M1 to M4 only) on the highest signal amplitude in
the displayed trace.
Marker to Valley: Press this key to set a Marker
(M1 to M4 only) on the lowest signal amplitude in the
displayed trace.
Back: Press this key to return to the Marker menu.
Markers 5 and 6 can perform a special Marker
search to find the Peak or Valley between two
other markers. When Marker 5 is Active:
Peak Between M1 & M2: Places Marker 5 on the
highest signal amplitude between Marker 1 and
Marker 2.
Valley Between M1 & M2: Places Marker 5 on the
lowest signal amplitude between Marker 1 and
Marker 2.
When Marker 6 is Active:
Peak Between M3 & M4: Places Marker 6 on the
highest signal amplitude between Marker 3 and
Marker 4.
Valley Between M3 & M4: Places Marker 6 on the
lowest signal amplitude between Marker 3 and
Marker 4.
Figure 4-5. Marker Menu (2 of 2)
