Cable and Antenna Measurements 3-14 Marker Menu
Marker Menu (Continued)
Key Sequence: Marker
Marker Search:
Tracking (On Off): When turned On, the active
marker becomes a tracking marker and defaults to
tracking the peak. To track Valleys, press the
Marker to Valley button after turning on Tracking. The
Search settings can all be applied to a Marker with
Tracking either On or Off.
Marker to Peak: Places the currently active marker on
the highest signal amplitude currently displayed on
screen.
Marker to Valley: Places the currently active marker
on the lowest signal amplitude currently displayed on
screen.
Markers 5, 6, 7, and 8 can perform a special Marker
search to find the Peak or Valley between two other
markers.
When Marker 5 or Marker 7 is Active:
Peak Between M1 & M2: Places Marker 5 or 7 on the
highest signal amplitude between Marker 1 and
Marker 2.
Valley Between M1 & M2: Places Marker 5 or 7 on the
lowest signal amplitude between Marker 1 and
Marker 2.
When Marker 6 or Marker 8 is Active:
Peak Between M3 & M4: Places Marker 6 or 8 on the
highest signal amplitude between Marker 3 and
Marker 4.
Valley Between M3 & M4: Places Marker 6 or 8 on the
lowest signal amplitude between Marker 3 and
Marker 4.
Figure 3-49. Marker Menu (2 of 2)
Peak
between
M1 & M2
Valley
between
M1 & M2
Marker to
Peak
Marker to
Valley
Marker Search
Tracking
Ma
rk
er t
o
Pe
ak
T
rac
k
in
g
On O
