S331L UG PN: 10580-00321 Rev. M 8-19
File Management 8-9 Create a Folder
8-9 Create a Folder
The Site Master S331L allows folders to be created in either internal
memory or an external USB drive. This functionality is helpful in
organizing traces by date, technician, carrier, and/or site location.
1. Press the File (1) key to display the File menu.
2. Press File Mgmnt to open the File Mgmnt dialog box.
3. Navigate to the location where you want to create the new folder.
4. Under File Mgmnt, press Create Folder to open the Foldername edit
box and on-screen keyboard.
5. Enter the new folder name. Optionally, you can use the EZ Name
keyboards to enter preset character strings. Refer to “EZ Name
Keyboards” on page 8-4.
6. Press Save to apply the new folder name and return to the File
Mgmnt dialog box.
Note
Double-tap a folder to open it. You can also use the Right and
Left keys on the keypad pane to open and close folders.
Figure 8-23. Enter a New Folder Name
