Anritsu Site Master S331L User Manual

12-12 PN: 10580-00321 Rev. M S331L UG
12-5 VIP Menus Video Inspection Probe (VIP)
Setup Menu
Key Sequence: Setup
Probe Model: This submenu key shows the currently
selected probe model. Press the key to display the list of
supported VIP models from which you can select.
Tip Type: Press this submenu key to display the Tip Type
selection box. Use the rotary knob or the
Up/Down arrow
keys to highlight the appropriate probe tip, then press Enter
to save the setting. See Table 12-1 on page 12-3 for a list
and description of possible selections.
To close the Tip Type dialog without making a change, press
the
Esc key.
Test Profile: Press this submenu key to select a profile that
matches the type of fiber being tested. Use the rotary knob
or the
Up/Down arrow keys to highlight the appropriate
probe tip, then press Enter to save the setting. See
Figure 12-3 on page 12-5.
Auto Analyze On/Off: When set to On, the fiber endface
image is automatically analyzed following capture. Select
Auto Analyze Off if you want to view the image before
manually executing the analysis.
Auto Filename On/Off: If Auto Filename is On, the file
naming scheme currently defined in the Auto Filename
Settings dialog is applied when you press the Save icon.
With Auto Filename Off, pressing the Save icon opens the
Save dialog the same way as pressing Save under the File
menu would.
Auto Filename Settings: Press this submenu key to open
a dialog box where you can preset the location and name of
files to be saved. See Figure 12-4 on page 12-5. You can
define a prefix (VIP is the factory default) and set the
starting number from which file numbering will increment.
You may also choose to include the current date in the file
name, in the format DDMMYYY. For example:
VIP_0001.vipi
VIP_21082015_0001.vipi
Figure 12-12.VIP Setup Menu
Setup
Tip Type
T
T
i
ip
p
p
T
y
p
e
Test Prole
e
e
s
s
st
t
t
Pr
o
l
e
Probe Model
G0306A
Auto Filename
A
u
On O
Auto Analyze
e
u
t
o
Fi
l
en
a
m
O
n
O

u
to Ana
l
yz
e
On O
Auto Filename
Settings
o
S
o
Se
o
e
F
e
F
t
F
il
enam
e
t
t
i
ng
s
