Instrument Overview 2-5 Touchscreen Display Overview
Main Menu Keys
These six main menu keys are horizontally arranged along the lower
edge of the touchscreen. The main menu key functions change based on
the instrument mode. The instrument mode is set with the Menu key or
the mode selector icon (not available in Classic mode). The main
menu keys generate function-specific submenus.
Submenu Keys
These submenu keys are arranged along the right-hand edge of the
touchscreen. The submenu keys change based on the selected Main
Menu or Keypad Menu key.
Several submenus may be displayed in the submenu block area. Press
any collapsed submenu title to expand the submenu and display the
submenu buttons. Press one of the submenu buttons to make a selection
or set a parameter.
6 Expanded submenu. Expanded submenus display the function
buttons.
7 Active trace sweeping between Start Frequency (F1) and Stop
Frequency (F2).
8 Marker Table. Refer to “Markers” on page 3-37.
9 Marker 1.
10 Main Menu keys with Freq/Dist selected. Refer to “Main Menu Keys ”
on page 2-13.
11 Warning and Status Area.
12 User-defined Shortcuts. Refer to “Menu Key” on page 2-6. Not
displayed in Classic Mode.
13 Graticule, a 10 x 10 grid showing the active trace.
14 Measurement Information. Displays current status. May also be
used as a touchscreen shortcut to submenus.
Figure 2-5. Site Master Display Overview (2 of 2)
