S331L UG PN: 10580-00321 Rev. M 2-5
Instrument Overview 2-3 Test Panel Connector Overview
3 USB Interface – Type A (version 2.0)
The Site Master has two Type A USB 2.0 connectors that accept USB
Flash Memory devices for storing or transferring measurements,
setups, and screen shots. Certain USB peripheral devices such as a
USB GPS module, USB mouse, or USB keyboard may also be
supported.
4 External Power
The external power connector is used to power the unit and for battery
charging. Input is 11 VDC to 14 VDC at up to 3.0 A. When using the
AC-DC Adapter, always use a grounded three-wire power cable that
is connected to a three-wire power line outlet. Failure to use properly
grounded electrical equipment may result in severe or potentially fatal
injury.
5 USB Interface – Type Mini-B (version 2.0)
The USB 2.0 Mini-B connector can be used to connect the Site
Master directly to a PC. The first time the Site Master is connected to
a PC, the normal USB device detection by the computer operating
system will take place.
When connecting the Site Master to a local area network, use an
Anritsu-approved USB-to-RJ45 adapter. The instrument will obtain an
IP address via DHCP, or a static IP address can be set by the user.
Refer to “Status Menu” on page 9-15 for information about obtaining
the IP address of the instrument.
6 Removable Torque Multiplier Nut
Used to assist in firmly securing RF cable(s) to the InstaCal/Power
Meter (4) port.
Figure 2-2. S331L Test Panel Connector (2 of 2)
